| Model | AGBST1030A | AGBST1515 |
|---|---|---|
| Capacity | 1000 Kgs | 1500 Kgs |
| Lifting Height (H) | 3000 mm | 1500 mm |
| Fork Size | 1150 * 150 mm | 1150 * 150 mm |
| Fork Arm Width | 600 mm | 600 mm |
| Load Center | 400 mm | 400 mm |
| Minimum Turning Radius (R) | 1450 mm | 1450 mm |
| Overall Length (A) | 1820 mm | 1820 mm |
| Overall Width (B) | 910 mm | 910 mm |
| Overall Height (H1) | 2080 mm | 2080 mm |
| Mast Height Closed | 3000 mm | 3000 mm |
| Lifting Speed Loaded | 0.11 m/sc | 0.11 m/sc |
| Lifting Speed Unloaded | 0.17 m/sc | 0.17 m/sc |
| Lowering Speed Loaded | 0.26 m/sc | 0.26 m/sc |
| Wheels | Nylon / PU | Nylon / PU |
| Battery Type | Traction Type lead Acid 24 Volt | Traction Type lead Acid 24 Volt |
| Battery Charger | In built Battery Charger | In built Battery Charger |
| Net weight Approximately | 360 Kgs | 360 Kgs |
| Battery | 1 Traction Type LED Acid 24 Volt Battery | 1 Traction Type LED Acid 24 Volt Battery |
